CRL 316 Brushed Stainless Z-Series Square Glass Clamp for 3/4" Glass
CRL 316 Brushed Stainless Z-Series Square Glass Clamp for 3/4" Glass
Regular price
$62.30 CAD
Regular price
Sale price
$62.30 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# Z934BS
Shipping Weight: 1.13 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 1.13 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Alloy
316
Base Type
Flat
Depth
3/4 in. (19 mm)
Finish/Color
Brushed Stainless Steel
Glazing Thickness
3/4 in. (19 mm)
Height
2-5/16 in. (59 mm)
Material
316 Stainless Steel
Profile
Square
Width
2-1/8 in. (54 mm)
Overview
- SKU: Z934BS — Z-Series Flat Surface Mount Glass Clamp
- For use with square tubing, square tube frames, or other flat mounting surfaces
- 316 alloy stainless steel construction (marine-grade corrosion resistance)
- Designed for 3/4" (19 mm) monolithic tempered glass — flat surface mounting
- One 7/8" (22 mm) diameter finger notch required; included steel pin must be used for 3/4" (19 mm) glass
- Includes rubber gaskets and steel pin; replacement screws: CRL P612
- Custom painted finishes available upon request
CRL Brushed Stainless Z-Series flat surface mount glass clamp (SKU Z934BS) for 3/4" (19 mm) glass, ideal for square tubing railings, glass partition frames, and other flat surface installations.
SPECIFICATIONS:
Glass Thickness: 3/4" (19 mm)
Base Design: Flat
Compatible With: Square tubing, square tube frames, and other flat surfaces
Material: 316 alloy stainless steel (marine-grade)
Glass Fabrication: One 7/8" (22 mm) diameter finger notch required; included steel pin required for 3/4" glass
Includes: Rubber gaskets and steel pin
Replacement Hardware: CRL P612 for replacement screws
Product Warning:
For interior and exterior applications CRL recommends pinning each glass panel when the glass is not supported from the bottom edge to prevent panel slippage. Rubber gaskets and steel pins are provided with each clamp.
Stainless Steel Advisory:
Although stainless steel is corrosion resistant, it is not rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in the Technical References section for details.
Order SKU Z934BS — contact CRL for pricing, lead times, or custom finishes.
