CRL Z-Series 316 Stainless Polished Square Glass Clamp for 3/4" Glass
CRL Z-Series 316 Stainless Polished Square Glass Clamp for 3/4" Glass
Regular price
$65.84 CAD
Regular price
Sale price
$65.84 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# Z934PS
Shipping Weight: 1.12 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 1.12 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Alloy
316
Base Type
Flat
Depth
3/4 in. (19 mm)
Finish/Color
Polished Stainless Steel
Glazing Thickness
3/4 in. (19 mm)
Height
2-5/16 in. (59 mm)
Material
316 Stainless Steel
Profile
Square
Width
2-1/8 in. (54 mm)
Overview
- For use with square tubing or other flat surfaces
- 316 alloy stainless steel glass clamp
- For 3/4" (19 mm) glass — flat surface mount
- Use monolithic tempered glass
- Custom painted finishes available upon request
CRL Brushed Stainless Z-Series flat surface mount square-type glass clamp for 3/4" (19 mm) glass. SKU: Z934PS.
SPECIFICATIONS:
Glass Thickness: 3/4" (19 mm)
Base Design: Flat — flat surface mount for square tubing or similar mounting surfaces
For Use With: Square tubing or other flat surfaces
Material: 316 alloy stainless steel (marine-grade)
Glass Fabrication: One 7/8" (22 mm) diameter finger notch required. Included steel pin must be used for 3/4" (19 mm) glass applications.
Includes: Rubber gaskets and steel pin
Replacement Hardware: CRL P612 for replacement screws
Product Warning:
For interior and exterior applications, CRL recommends pinning each glass panel when the glass is not supported from the bottom edge to prevent panel slippage. Rubber gaskets and steel pins are provided with each clamp.
Stainless Steel Advisory:
Although stainless steel is corrosion-resistant, it is not rust- or stain-proof. CRL recommends periodic maintenance to help maintain the factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.
Heavy-duty, marine-grade 316 stainless steel construction and flat-surface mounting make the Z934PS ideal for architectural glass railing, balustrades, and commercial storefronts requiring a secure 3/4" (19 mm) tempered glass clamp. Contact CRL to order or request custom painted finishes.
