CRL 316 Polished Stainless Laguna Series Wall Mount Single Slider with Softbrake Kit
CRL 316 Polished Stainless Laguna Series Wall Mount Single Slider with Softbrake Kit
Regular price
$1,747.72 CAD
Regular price
Sale price
$1,747.72 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# LSWM7PS
Shipping Weight: 23.0 Pounds
Shipping Limitations: None
Warning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
Shipping Weight: 23.0 Pounds
Shipping Limitations: None
This Product Ships Free!
Compliance and RestrictionsWarning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
Description
| Anti-Lift Yes | Attachment Flush, Surface |
| Door | Configuration Single Door |
| Finish/Color | Polished Stainless Steel |
| Glazing Thickness | 3/8 in. or 1/2 in. (10 mm or 12 mm) |
| Glazing | Type Tempered Monolithic |
| Material | 316 Stainless Steel |
| Maximum Door Height 98-7/16 in. | (2500 mm) |
| Maximum Panel Weight 220 lbs. | (100 kg) |
| Minimum Door Width 37-13/16 in. | (960 mm) |
| Mounting | Application Wall |
| Track Diameter 1-1/4 in. | (32 mm) |
| Track Length 104 in. | (2642 mm) |
Overview
The CRL Laguna Series Wall Mount Single Slider with Softbrake Kit is an essential solution for single door installations, offering a Softbrake braking system that smoothly controls the last 2-1/4" of travel.
Designed for use with 3/8" or 1/2" tempered glass, this kit includes all necessary hardware for easy installation on reinforced walls.
The innovative Anti-Lift Sliding Door Top Rollers provide versatile attachment options and a 1/8" vertical adjustment for precise door alignment.
Built with durable Alloy 316 Stainless Steel, the system supports doors up to 220 lbs, with width and height limitations to ensure optimal performance.
For best results, periodic maintenance of the stainless steel components is recommended to maintain their factory finish.
Designed for use with 3/8" or 1/2" tempered glass, this kit includes all necessary hardware for easy installation on reinforced walls.
The innovative Anti-Lift Sliding Door Top Rollers provide versatile attachment options and a 1/8" vertical adjustment for precise door alignment.
Built with durable Alloy 316 Stainless Steel, the system supports doors up to 220 lbs, with width and height limitations to ensure optimal performance.
For best results, periodic maintenance of the stainless steel components is recommended to maintain their factory finish.
