CRL Black Bronze Anodized 6x10 LHR Center Push Button Lock w/ Housing

• Requires No Electrical Connections
• Complies with A.D.A. Standards
• Five Finishes Available
• Use Monolithic Tempered Glass

CRL 6" x 10" Center Locks with Deadlatch (SKU: DL611LCDU) deliver versatile lock functions and enhanced security for 1/2" (12 mm) heavy tempered glass doors. Designed for easy retrofit or new installs, the lock requires only a simple glass cut-out—no cement or silicone—and is available in five attractive finishes and left- or right-handed orientations. Ideal long-tail search terms: center lock for glass doors, 6x10 center lock deadlatch for tempered glass, ADA-compliant glass door lock.

Key Differentiators:

• Deadlatch design resists jimmying for improved security
• ADA-compliant operation and no electrical connection required
• Quick installation—simple glass cut-out; no messy adhesives
• Fits 1/2" (12 mm) monolithic tempered glass doors; five finish options

Office Lock Function: Latchbolt operates by lever on either side (outside lever may be locked by faceplate rocker) or by key outside. Auxiliary latchbolt deadlocks the main latchbolt to prevent jimmying. Inside lever always retracts for egress.

Entrance Lock: Latchbolt operates by lever (except when deadbolt is projected). Deadbolt is keyed outside and thumbturn inside. Inside lever retracts both latch and deadbolt for egress.

Passage Lock: Latchbolt operates by lever on either side. Inside lever always retracts for egress.

Storeroom Lock: Latchbolt operates by inside lever and by key outside; outside lever is fixed. Auxiliary latchbolt deadlocks the main latchbolt. Primarily used with electric strikes.

Classroom Lock: Latchbolt operates by lever either side except when outside lever is locked by key. Key operates latch and unlocks outside lever; inside lever is always operable.


Product Warning:

Black Bronze cover plate with Satin Anodized lock and lever.
