CRL Brass Victoria Series Wall Mount Full Back Plate Hinge
CRL Brass Victoria Series Wall Mount Full Back Plate Hinge
Regular price
$147.66 CAD
Regular price
Sale price
$147.66 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# VCT037BR
Shipping Weight: 3.025 Pounds
Shipping Limitations: None
Warning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
Shipping Weight: 3.025 Pounds
Shipping Limitations: None
This Product Ships Free!
Compliance and RestrictionsWarning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
Description
| 5 Degree Pre-Set No | No |
| Back | Plate Full |
| Construction | Solid |
| Finish/Color | Polished Brass |
| Glazing Thickness | 3/8 in. To 1/2 in. (10 mm To 12 mm) |
| Height 4-3/8 in. | (111 mm) |
| Material | Brass |
| Maximum Door Weight 140 lbs. | (63.5 kg) |
| Maximum Door Width 39 in. | (991 mm) |
| Mounting | Type Wall Mount |
| Self-Centering Yes | Victoria |
| Width 2-15/16 in. | (75 mm) |
Overview
The CRL Victoria Series Hinges are an excellent choice for heavier and wider shower doors, capable of supporting up to 140 lbs.
(64 kg) with a maximum width of 39" (1 m) using only two hinges.
These hinges, crafted from solid brass, feature an integrated safety interlock to enhance glass panel control and are available in both wall mount and 180-degree glass-to-glass models.
Designed for 3/8" to 1/2" (10 to 12 mm) thick tempered safety glass, they provide a frameless aesthetic by minimizing hardware, while their heat-treated stainless steel springs ensure durability and increased self-centering force.
Available in six popular finishes with custom options, these hinges require precise glass fabrication and should not exceed specified weight or width capacities for optimal performance.
(64 kg) with a maximum width of 39" (1 m) using only two hinges.
These hinges, crafted from solid brass, feature an integrated safety interlock to enhance glass panel control and are available in both wall mount and 180-degree glass-to-glass models.
Designed for 3/8" to 1/2" (10 to 12 mm) thick tempered safety glass, they provide a frameless aesthetic by minimizing hardware, while their heat-treated stainless steel springs ensure durability and increased self-centering force.
Available in six popular finishes with custom options, these hinges require precise glass fabrication and should not exceed specified weight or width capacities for optimal performance.
