CRL Brite Chrome Vernon Oil Dynamic Full Back Plate Wall-to-Glass Hinge - Hold Open
CRL Brite Chrome Vernon Oil Dynamic Full Back Plate Wall-to-Glass Hinge - Hold Open
Regular price
$588.09 CAD
Regular price
Sale price
$588.09 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# H8010CH
Shipping Weight: 1.678 Pounds
Shipping Limitations: None
Warning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
Shipping Weight: 1.678 Pounds
Shipping Limitations: None
This Product Ships Free!
Compliance and RestrictionsWarning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
Description
| Adjustable | Closing Speed Yes |
| Finish/Color | Polished Chrome |
| Glazing Thickness | 5/16 in., 3/8 in., 1/2 in., 9/16 in. (8 mm, 10 mm, 12 mm, 14 mm) |
| Hold | Open Yes |
| Material | Aluminum |
| Maximum Door Width 39 in. | (991 mm) |
| Mounting | Type Wall Mount |
| Weight Capacity 220 lbs. | (99.8 kg) |
| Width 1 in. | (25 mm) |
Overview
The CRL Full Back Plate Wall Mount Hinge is perfect for self-closing glass doors with thicknesses ranging from 5/16" to 9/16" (8 to 13.52 mm), making it ideal for interior applications, especially in bathroom areas.
Featuring an adjustable closing speed, it offers a superior alternative to floor closers and patch fittings, allowing for seamless installation without extensive retrofitting.
With an aluminum body available in various finishes, the Oil Dynamic Hinge supports doors up to 39" wide and 220 lbs, ensuring durability with over 1 million cycles tested.
Designed for versatility, it swings 90º in and out with stops at 0º, +90º, and –90º, and is suitable for monolithic tempered glass.
Featuring an adjustable closing speed, it offers a superior alternative to floor closers and patch fittings, allowing for seamless installation without extensive retrofitting.
With an aluminum body available in various finishes, the Oil Dynamic Hinge supports doors up to 39" wide and 220 lbs, ensuring durability with over 1 million cycles tested.
Designed for versatility, it swings 90º in and out with stops at 0º, +90º, and –90º, and is suitable for monolithic tempered glass.
