CRL Monterey S80CW 3+3 Bi-Fold Ext Door Bronze Anodized w/ Lever Lock

CRL Monterey S80CW 3+3 Bi-Fold Ext Door Bronze Anodized w/ Lever Lock

Shipping calculated at checkout.
Quantity
Item# M3B33R0DUL
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
Black Bronze Anodized
Glazing Thickness
1 in. (25 mm)
Maximum Panel Width
36 in. (914 mm)
Panel Count
6

Overview

  • Meets CW performance rating minimum design pressure of 30 psf
  • Meets CW performance rating maximum allowable deflection of L/175
  • Thermally broken with 1-inch insulating glass
  • For low- to mid-rise commercial applications
  • Maximum panel width: 36 inches; maximum frame height: 10 feet

The Monterey S80CW Bi-Folding Door is a commercial bi-folding door engineered for demanding exterior applications. Its CW Performance Class rating delivers higher load capacity, stricter deflection control, and durable weather performance—making it ideal for high-traffic, low- to mid-rise commercial projects that require larger panels and enhanced structural reliability.

  • Outswing operation with raised sill
  • Maximum interconnected panels: 9
  • Floating panel option available in even sets
  • Standard finishes: black bronze anodized, satin anodized, black & white 90% gloss powder coat
  • Custom powder coat finishes available

Most shipping weights are approximate and have not been verified. If exact weight is required to determine shipping costs, request this prior to ordering by contacting CRL Customer Service. Product images shown are representative; colors may vary by monitor.

SKU: M3B33R0DUL


Highlighting: thermally broken frame, 1" insulating glass, CW-rated structural performance—perfect for commercial storefronts, restaurants, hotels, and office façades. Request a quote or contact CRL Customer Service to discuss specifications and finish options.

Specifications
