CRL Brushed Bronze Adjustable Sleeve-Over Glass Clamp for Railings

• For 5/16" to 1/2" (8 to 12 mm) thick glass
• Use monolithic tempered glass
• Adjustable from 90° to 180°
• Solid brass construction
• Assists with shear forces on glass panels
• Holds glass panels in position while sealant cures

CRL Sleeve Over Glass Clamps are solid-brass, sleeve-over-glass clamps engineered to absorb shear forces and temporarily secure monolithic tempered glass panels—no special glass fabrication required. Clamps tighten with nylon-tipped Allen set screws and include gaskets to protect glass. Ideal for frameless shower or partition installations where mechanical support is needed during silicone cure time; silicone provides watertight sealing and the long-term pull strength of the joint.

SPECIFICATIONS:
SKU: S0GC91BBRZ
Material: Solid Brass
Glass Thickness Range: 5/16" to 1/2" (8 to 12 mm)
No Glass Fabrication Required: Clamps secure with nylon-tipped Allen screws
Includes: Gaskets

NOTE: Not designed to replace headers or a support bar. Can be used on square-cut or mitered panels. Contact CRL Frameless Shower Technical Sales for application guidance.

Product Warning:

These clamps are not intended to substitute for headers or a support bar.

Contact CRL Frameless Shower Technical Sales or order SKU S0GC91BBRZ today.
