CRL Brushed Nickel 180° Movable Transom Glass-to-Glass Clamp

• For 3/8" to 1/2" (10 to 12 mm) thick glass
• Glass transom swivels to allow release of steam
• Wall mount and 180º models available
• Solid brass construction for corrosion resistance
• Designed for monolithic tempered glass

CRL Beveled 180º Glass-to-Glass Movable Transom Clamps (SKU BGC188BN) allow rotation of a movable transom away from an inline fixed glass panel. This beveled, 180° glass-to-glass transom clamp is ideal for shower and partition applications that need steam release or quick access. Use in combination with Cat. No. BGC186 Wall Mount Movable Transom Clamp when required. Clamp must be centered on the transom for balanced movement.

Replacement parts: Cat. Nos. 90295A120 (nylon washer), 211039 (10-32 x 3/4" flat head Phillips screw), 193004 (10-32 nylon lock nut), and BGCU1G (gasket).

NOTE: Maximum transom size is 16" x 30" (406 x 762 mm). Larger transoms require pivot hinges used as transom clamps—call for details.

SPECIFICATIONS:
Materials: Solid Brass
Glass Thickness Range: 3/8" to 1/2" (10 to 12 mm)
Glass Fabrication Required: BGC180, BGC135, BGC90, and BGC186 require 3/4" (19 mm) holes; BGC188 requires a 3/4" (19 mm) hole in the fixed panel and a notch in the transom
Includes: Gaskets


Call or order now to get the BGC188BN beveled 180º glass-to-glass movable transom clamp for your tempered glass shower or partition project.
