CRL AMR215 Brushed Stainless Double-Keyed Door Lock Cylinder
CRL AMR215 Brushed Stainless Double-Keyed Door Lock Cylinder
Regular price
$59.96 CAD
Regular price
Sale price
$59.96 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# AMR215CCBS
Shipping Weight: 1.0 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 1.0 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Diameter
1-5/32 in. (29 mm)
Finish/Color
Brushed Stainless Steel
Overview
- High-density cast body with secure lock mechanism
- Gaskets for use with 3/8" or 1/2" (10 or 12 mm) glass
- Five architectural finishes for design flexibility
The American Style Patch Lock (SKU: AMR215CCBS) is a heavy-duty patch lock for glass doors and a robust alternative to the AMR205. Its taller profile secures more glass inside the housing for enhanced perimeter security. Designed specifically for top and bottom corner applications, this patch lock accepts either double-keyed cylinders or a keyed cylinder with thumbturn (ordered separately). A keeper is supplied; optional keepers are available to fit most installations.
GLASS FABRICATION REQUIRED:
Top or Bottom Mount:
One 3/4" (19 mm) diameter hole and one corner notch required on the glass.
COMES WITH: Template and instructions for glass door patch lock installation.
DOES NOT INCLUDE:
Double-keyed cylinders; keyed cylinder/thumbturn; optional keepers (must be ordered separately).
DOUBLE DOOR APPLICATION:
For double-door installations, a bottom patch lock is required on the inactive leaf to properly secure the pair of doors.
Stainless Steel Advisory:
Although stainless steel is highly corrosion-resistant, it is not completely rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. For details, see the Stainless Steel Disclaimer in the Technical References section below.
