• Brushed stainless steel AFWC2 fascia clamp for 10-12-14 mm tempered glass, surface mount, 5-5/8" high
1 1

CRL

CRL Brushed Stainless Two-Piece Side-Mount Frameless Glass Clamp

CRL Brushed Stainless Two-Piece Side-Mount Frameless Glass Clamp

$125.47 CAD
$125.47 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# AFWC2
Shipping Weight: 1.08 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Attachment
Fascia
Finish/Color
Brushed Stainless Steel
Glazing Thickness
3/8 in., 1/2 in., 9/16 in. (10 mm, 12 mm, 14 mm)
Material
Stainless Steel

Overview

  • Designed for 3/8" or 1/2" (10 or 12 mm) tempered monolithic glass and 9/16" (13.52 mm) tempered laminated glass
  • Surface mounts to face of wall or planter box

CRL Two-Piece Clamps (SKU: AFWC2) attach to the front side of walls or planter boxes. Glass fabrication requires two 3/4" (19 mm) holes per clamp. Height: 5-5/8" (143 mm).

CRL frameless windscreen clamps are ideal for creating a low-profile tempered glass windscreen or glass pool surround with minimal visual obstruction from vertical or horizontal framing. Four styles fit core-drilled holes in concrete decks filled with expanding cement; additional models mount to wall faces or planter boxes, and surface-mount options are available. Custom powder-coated finishes can be requested for matching architectural or landscape projects.

NOTE: CRL is an international supplier. Check local building codes to confirm these frameless windscreen clamps meet regional regulations.

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs, please request this prior to submitting your order by contacting CRL Customer Service. Product images show the actual product or a close representation; colors may vary by monitor.

Stainless Steel Advisory:
Stainless steel is corrosion-resistant but not completely rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in the Technical References section for details.


Order AFWC2 frameless windscreen clamps for durable, low-profile tempered glass mounting—contact CRL Customer Service to confirm specifications and finishes.
