CRL Matte Black Right-Hand Offset Bottom Glass Door Patch Fitting
Item# 0PF10RMBL
Shipping Weight: 3.5 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 3.5 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Buy More, Save More!
| Product QTY | Discount |
|---|---|
| Buy 3 | 3% Off |
| Buy 5 | 6% Off |
| Buy 8 | 9% Off |
| Buy 11 | 12% Off |
| Buy 16 | 16% Off |
Finish/Color
Matte Black
Glazing Thickness
3/8 in., 1/2 in. (10 mm, 12 mm)
Handing
Right Hand
Series
Offset
Type
Bottom
- Allows for 180º Door Swing
- For 3/8" or 1/2" (10 or 12 mm) Glass
- Left and Right Handed
The CRL Bottom of Door Offset Patch Fitting (SKU: 0PF10RMBL) is a glass door offset patch fitting engineered for a full 180° door swing. Works with 3/8" or 1/2" (10 or 12 mm) tempered glass and is available in brushed or polished stainless steel finishes. Left- and right-handed configurations accommodate varied installation layouts. Glass fabrication templates and step-by-step instructions are included.
INCLUDES:
- High density cast body
- Cover plates in chosen finish
- Gasket for 3/8" or 1/2" (10 or 12.7 mm) glass
- Template and instructions
SPECIFICATIONS:
- For use with CRL8300 Series floor closers
- For use with CRL8400 Series floor closers
- Compatible with INT402 bottom free-swinging pivot
- Compatible with INT403 adjustable bottom free-swinging pivot
- Compatible with INT406 adjustable bottom free-swinging pivot
GLASS FABRICATION REQUIRED:
One 3/4" (19 mm) diameter hole and corner notch.
COMES WITH:
Template and instructions
Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs, request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your monitor and video card settings.
Why choose this offset patch fitting? Durable stainless steel finishes, included templates for fast glass fabrication, and compatibility with multiple CRL floor closers and pivots make it a reliable choice for frameless glass doors requiring a full 180° swing.
CAD Drawings - dwg
