CRL AMR215 Polished Stainless Patch Lock for Frameless Glass Doors
CRL AMR215 Polished Stainless Patch Lock for Frameless Glass Doors
Regular price
$159.91 CAD
Regular price
Sale price
$159.91 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# AMR215PS
Shipping Weight: 2.0 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 2.0 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Polished Stainless Steel
Glazing Thickness
3/8 in.,1/2 in. (10 mm,12 mm)
Height
2-9/16 in. (65 mm)
Width
6-1/8 in. (156 mm)
Overview
- High-density cast body with internal lock mechanism
- Gaskets for use with 3/8" or 1/2" (10 or 12 mm) glass
- Available in five architectural finishes
The American Style Patch Lock (SKU: AMR215PS) is a heavy-duty top/bottom corner patch lock designed for frameless glass doors where increased glass retention and security are required. Its taller profile secures more glass inside the lock housing for added strength. Install only in top or bottom corner applications. Cylinders (double-keyed or keyed cylinder/thumbturn) are ordered separately. A keeper is supplied; optional keepers are available for most installations.
GLASS FABRICATION REQUIRED:
Top or Bottom Mount:
One 3/4" (19 mm) diameter hole and one corner notch
COMES WITH: Template and instructions
DOES NOT INCLUDE:
Double-keyed cylinders; keyed cylinder/thumbturn; optional keepers (must be ordered separately)
DOUBLE DOOR APPLICATION:
For double door installations, a bottom patch lock is required on the inactive leaf to properly secure the pair of doors.
Product Warning:
Cylinders are optional and not included with the lock body.
Stainless Steel Advisory:
Stainless steel resists corrosion but is not rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in Technical References for details.
Key features: heavy-duty patch lock for frameless glass doors, top/bottom corner mount, compatible with 3/8"–1/2" glass, five architectural finishes.
Order AMR215PS today to secure your frameless glass doors—contact CRL or your distributor to add cylinders and optional keepers.
