CRL Satin Anodized Double Narrow Glass Header with Top Pivots 72 in

• For use with 1/2" (12 mm) glass only — use monolithic tempered glass
• Supported by glass side panels
• Creates an even sight line when used with CRL door rails
• Stock headers: Single 36" (914 mm) and Double 72" (1.83 m); custom sizes available
• Six standard architectural finishes; custom finishes available on special order

CRL Narrow Floating Headers with Walking Beam Top Pivots are engineered for 1/2" (12 mm) heavy glass door rails and work with CRL PH20 and PH21 Series top door patch hardware fittings. When paired with CRL door rails the narrow header matches the rail width for an even sight line—an ideal solution when you want maximum glass visibility with a coordinated header-to-rail appearance. These narrow floating headers are fabricated for 1/2" (12 mm) glass-to-glass configurations and are compatible with free-swinging bottom pivots or floor closers. Custom lengths, glass-to-wall configurations, and floating headers for offset pivots are available.

Compatible hardware: CRL PH20/PH21 top door patch fittings and CRL9040WBP walking beam top pivots.

Application Tip: Use the CRL Narrow Floating Header to maximize glass area while retaining the security of a magnetic shear lock.

Product Warning:

STRUCTURAL DISCLAIMER - Customers must consult a structural engineer to confirm suitability for intended use and site conditions. Installers must be qualified and ensure compliance with local, state, and federal regulations, appropriate fixing materials, and safe installation procedures.

If the weight of the transom above the header exceeds 100 lbs. (45.4 kg), support the transom from the ceiling to prevent header bowing. Use Cat. No. B5BC Smoke Baffle Channel or PH94 Patch Fittings as needed. Contact CRL Technical Sales for assistance.

Stock Narrow Floating Headers: For 1/2" (12 mm) glass-to-glass installations with CRL9040WBP walking beam top pivots.

SKU: NFH4SAD


Contact CRL Technical Sales for specifications
