CRL
CRL Vertical Panel Connector
Item# Y04CR
Shipping Weight: 2.816 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 2.816 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Buy More, Save More!
| Product QTY | Discount |
|---|---|
| Buy 3 | 3% Off |
| Buy 5 | 6% Off |
| Buy 8 | 9% Off |
| Buy 11 | 12% Off |
| Buy 16 | 16% Off |
Finish/Color
Polished Nickel
Glazing Thickness
1/4 in. To 3/8 in. (6 mm To 10 mm)
Material
Brass
- Hang vertical glass panels and mirrors securely in high-moisture environments
- Requires a drilled hole in the glass or panel (minimum 1/4" / 6 mm)
- Component for CRL cable systems for 1/4" to 3/8" (6 to 10 mm) glass
CRL Vertical Panel Connectors (SKU: Y04CR) are designed for hanging 1/4" to 3/8" (6 to 10 mm) mirrors or glass panels where edge clamping is unsuitable—ideal for bathrooms, spas, and humid commercial environments. These connectors allow cable installations behind the panel and require a minimum 1/4" (6 mm) drilled hole; 3/8" (10 mm) holes may be required for 3/8" (10 mm) tempered glass. Load capacity: 20 lbs. (9 kg) for 1/4"–5/16" (6–8 mm) panels and 10 lbs. (4.5 kg) for 3/8" (10 mm) panels.
Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs before ordering, please contact CRL Customer Service. Product images are of the actual item or a close representation; colors may vary by monitor.
Order CRL Y04CR Vertical Panel Connectors for secure, moisture-resistant glass hanging—contact sales to buy.
