• CRL50 Series Two Panel Telescoping Kit - Ceiling Mount, Right Stack, Behind Fixed Panel
  • CRL50 Series Telescoping Ceiling Mount Kit - Right Stack, 2 Panel, Fixed Panel Design
  • CRL50 Series Two Panel Telescoping Ceiling Mount Kit - Right Stacking, Sleek Design
1 3

crlaurence.ca

CRL50 Series Two Panel Telescoping Behind Fixed Panel Ceiling Mount Kit - Right Stacking Direction

CRL50 Series Two Panel Telescoping Behind Fixed Panel Ceiling Mount Kit - Right Stacking Direction

$2,970.07 CAD
$2,970.07 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# CRL501CP2R
Shipping Weight: 125.98 Pounds
Shipping Limitations: None
This Product Ships Free!
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
View full details

Product Information

Description

Finish/ColorSatin Anodized
Glazing Thickness3/8 in. (10 mm)
GlazingType Tempered Insulated
Maximum Panel Weight 176 lbs.(80 kg)
MountingApplication Ceiling
TopHung Yes
Track Length 118 in.(2997 mm)

Overview

The CRL50 Series Kits offer versatile telescoping operation for 5/16" or 3/8" (8 to 10 mm) tempered glass doors, ideal for monolithic glass installations.
These kits accommodate doors weighing up to 176 lbs.
(80 kg) and a maximum width of 40-3/8" (1025 mm), providing seamless sliding and stacking functionality.
Available in satin anodized finishes, with options for powder paint or cladding in any architectural finish, they come complete with all necessary components except the tempered glass.
For kit selection or installation assistance, contact Technical Sales for Commercial Products.
Note: Laminated glass is not recommended for use with the CRL50 System.
Always consult a structural engineer for suitability and compliance with local regulations.
