CRL Brite Chrome Wall-to-Glass Shower Hinge - Back Plate Hold-Open

• For self-closing glass doors 5/16" to 9/16" (8 to 13.52 mm) thick
• Designed for interior doors (not for shower doors)
• Aluminum body available in multiple finishes
• Adjustable closing speed (oil-damped)
• Great alternative to floor closers and patch fittings for all-glass installations
• Use with monolithic tempered glass

CRL Full Back Plate Wall Mount Hinge (SKU H8010CH) swings in and out a full 90º with positive stops at 0º, +90º and –90º. The oil-dynamic mechanism combines automatic mechanical hinge action with hydraulic damping to deliver smooth, adjustable self-closing performance—ideal for interior bathroom doors where a floor or overhead closer is undesirable. Closing speed is adjustable via a control valve. Use two hinges for doors up to 39" (1 m) wide; maximum combined weight for two hinges is 220 lbs. (100 kg).

The Oil Dynamic Hinge allows installation of an all-glass, self-closing door without floor or overhead retrofitting. It is ambidextrous, supports monolithic tempered glass, and has been tested for long life (over 1 million cycles).

SPECIFICATIONS:
Glass Thickness Range: 5/16" to 9/16" (8 to 13.52 mm)
Construction: Aluminum
Hinge Swings: 90º inwards and outwards (except H8060 model)
Closing Type: Automatic closing from 0º to 80º (oil-damped)
Special Features: Holds open at 90º; adjustable closing speed. No-hold-open versions available (except H8060)
Cut-Out Required
Includes: Snap-in molded gaskets for 5/16" to 9/16" (8 to 14.2 mm) glass; hex screws
Maximum Capacities Using Two Hinges: Door Width: 39" (1 m); Door Weight: 220 lbs. (100 kg)

NOTE: Do not use more than two hinges on one door.

Product Warning:
Do not use more than two hinges on one door. If hinges are used for other than intended purposes, obtain approval from CRL Technical Sales. Use only the template included with the hinge—cut-out dimensions may differ from other brands.
