CRL Brushed Satin Nickel Wall-to-Glass Hold-Open Hinge Backplate

• For self-closing glass doors 5/16" to 9/16" (8 to 13.52 mm) thick
• Designed for interior use (not for shower doors)
• Aluminum body available in multiple finishes
• Adjustable closing speed with oil-damped operation
• Alternative to floor closers and patch fittings for all-glass retrofits
• Use with monolithic tempered glass only

This CRL Full Back Plate Wall Mount Hinge (SKU H8010SN) is an oil-dynamic, self-closing hinge that swings a full 90° both in and out with positive stops at 0°, +90° and −90°. Closing speed is adjustable via a control valve. Suitable for glass doors up to 39" (1 m) wide; maximum capacity for two hinges is 220 lbs (100 kg).

The Oil Dynamic Hinge blends automatic mechanical hinge convenience with hydraulic door closer performance. Ideal for interior bathroom doors where a self-closing, all-glass solution is required without floor- or overhead-mounted hardware, this wall-mount hinge makes retrofit installations simple and clean.

When properly mounted, two Oil Dynamic Hinges support 5/16"–9/16" (8–13.52 mm) tempered glass doors up to 39" (1 m) wide and 220 lbs (100 kg). The hinge is ambidextrous, includes positive 0° and 90° stops, and offers an adjustable closing speed for controlled operation.

The Oil Dynamic Hinge features a durable aluminum body in configurations for Wall Mount and Glass-to-Glass applications. It has been cycle-tested for long service life (over 1 million cycles).

SPECIFICATIONS:
Glass Thickness Range: 5/16" to 9/16" (8 to 13.52 mm)
Construction: Aluminum
Swing: 90° inwards and outwards (except H8060 model, one-way only)
Closing Type: Automatic closing from 0° to 80° (oil-damped)
Special Features: Holds open at 90°; adjustable closing speed. (No hold-open models except H8060.)
Cut-Out Required
Includes: Snap-in molded gaskets for 5/16"–9/16" (8–13.52 mm) glass; hex screws
Maximum Capacities Using Two Hinges: Door width: 39" (1 m); Door weight: 220 lbs (100 kg)

NOTE: Do not use more than two hinges on one door.

Product Warning:

Do not use more than two hinges on a single door. For applications other than intended use, obtain approval from the CRL Technical Sales Department. Use only the included hinge template—cut-out dimensions for CRL hinges may differ from other brands.
