CRL Lugano Brushed Bronze Wall Mount Door Hinge - Left-Hand
CRL Lugano Brushed Bronze Wall Mount Door Hinge - Left-Hand
Regular price
$246.00 CAD
Regular price
Sale price
$246.00 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# LUG044RBBRZ
Shipping Weight: 1.125 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 1.125 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Back Plate
Offset
Design Style
Concealed/Premium
Edge Profile
Square
Enclosure Type
Corner, Niche, Bathtub, Tailor Made Solutions
Finish/Color
Brushed Bronze
Glazing Thickness
5/16 in. To 3/8 in. (8 mm To 10 mm)
Handing
Left Hand
Height
1-31/32 in. (50 mm)
Material
Brass
Maximum Door Weight
99 lbs. (44.9 kg)
Maximum Door Width
35 in. (889 mm)
Mounting Type
Wall Mount
Opening Style
Swing(side)
Series
Lugano
Width
1-31/32 in. (50 mm)
Overview
- Rise-and-fall action: 3/16" (5 mm)
- Sleek Lugano Series hinge design — modern low-profile finish
- Fits 5/16" to 3/8" (8 to 10 mm) glass
- Ideal for pitched curb installations
- Use with no-ledge threshold for wheelchair-accessible glass doors
- Flush mount inside for easy-to-clean shower glass
- Snap-on covers conceal screws for a seamless look
- Rigorously tested to 100,000 cycles — 5× the industry standard
The Lugano Series hinge (SKU: LUG044RBBRZ) is a self-centering glass hinge that activates within 60° of the closed position. Designed for 5/16"–3/8" (8–10 mm) tempered glass, it supports up to 99 lb (44 kg) per door when using two hinges and accommodates a maximum door width of 35". All fasteners are concealed to maintain a clean, contemporary appearance suitable for frameless glass shower doors and ADA-friendly, no-ledge installations.
Order the Lugano Series hinge LUG044RBBRZ today to upgrade your frameless glass shower or wheelchair-accessible door—contact customer service for weight or installation guidance.
