CRL Satin Anodized LH North American Bottom Door Patch Fitting
Item # PH10ELA
$73.86
CAD
Finish (4)
-
Satin Anodized -
Brushed Stainless Steel -
Black Bronze Anodized -
Matte Black
Type (3)
- Bottom
- Top
- Top or Bottom
Overview
| SKU | PH10ELA |
|---|---|
| Sold As | 1 Each |
| Finish/Color | Satin Anodized |
| Glazing Thickness | 3/8 in., 1/2 in. (10 mm, 12 mm) |
| Handing | Left Hand |
| Insert Type | 1NT305L |
| Pivot Setback | 2-3/4 |
| Series | North American |
| Type | Bottom |
| With Insert | Yes |
Description
- For 3/8" or 1/2" (10 or 12 mm) Tempered Glass
- 2-3/4" (70 mm) Pivot Setback
- For Herculite™+ Style Doors
For Use With:
Includes:
Product Warning:
For maximum door size when using this product, CRL follows GANA Guidelines.
Specifications
Templates
CAD Drawings - pdf
- PDFCommercial Patch Hardware European Series System CAD Drawings.pdf
- PDFCommercial Patch Hardware North American Series System CAD Drawings.pdf
- PDFCommercial Patch Hardware Wedge Lock 3-8 inch Glass to 1-2 inch Glass System CAD Drawings.pdf
- PDFCommercial Patch Hardware Wedge Lock 5-8 inch Glass to 3-4 inch Glass System CAD Drawings.pdf
CAD Drawings - dwg
- DocumentCommercial Patch Hardware European Series System CAD Drawings.dwg
- DocumentCommercial Patch Hardware North American Series System CAD Drawings.dwg
- DocumentCommercial Patch Hardware Wedge Lock 3-8 inch Glass to 1-2 inch Glass System CAD Drawings.dwg
- DocumentCommercial Patch Hardware Wedge Lock 5-8 inch Glass to 3-4 inch Glass System CAD Drawings.dwg
