CRL Matte Black LH Bottom Patch Fitting for Frameless Glass Doors
Item# PH10ELMBL
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Buy More, Save More!
| Product QTY | Discount |
|---|---|
| Buy 3 | 2% Off |
| Buy 5 | 4% Off |
| Buy 10 | 6% Off |
| Buy 15 | 8% Off |
| Buy 20 | 10% Off |
Finish/Color
Matte Black
Glazing Thickness
3/8 in., 1/2 in. (10 mm, 12 mm)
Handing
Left Hand
Insert Type
1NT305L
Pivot Setback
2-3/4
Series
North American
Type
Bottom
With Insert
Yes
- Fits 3/8" or 1/2" (10 or 12 mm) tempered glass panels
- 2-3/4" (70 mm) pivot setback for precise door swing
- Designed for Herculite™+ style glass doors and storefront installations
For Use With:
- 3/8" or 1/2" (10 or 12 mm) tempered glass
- Glass fabrication required: one 3/4" (19 mm) diameter hole and corner notch
- Installation template available at crlaurence.com
Includes:
- 1 × AMR201 door patch
- 1 × 1NT305L and 1 × 1NT305R bottom door patches
- Insert gaskets for 3/8" or 1/2" (10 or 12 mm) glass
Product Warning:
For maximum door size when using this product, CRL follows GANA Guidelines.
Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs, please request this prior to submitting your order by contacting CRL Customer Service. Product images are of the actual product or a close representation; colors may vary depending on monitor settings.
SKU: PH10ELMBL
High-quality glass door patch fitting optimized for Herculite™+ storefront and commercial glass doors — ideal for retrofit and new construction. Order now to get precise, durable hardware and download the template at crlaurence.com.
CAD Drawings - dwg
