CRL 18 in Polished Stainless Steel Mitered Corner Glass Door Pull
CRL 18 in Polished Stainless Steel Mitered Corner Glass Door Pull
Regular price
$137.57 CAD
Regular price
Sale price
$137.57 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# MH18X18PS
Shipping Weight: 2.537 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 2.537 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Polished Stainless Steel
Glazing Thickness
3/8 in. (10 mm)
Mounting Center To Center
18 in. (457 mm)
Mounting Hole Diameter
5/8 in. (16 mm)
Mounting Type
Back-to-Back
Style Washer Diameter
1-1/4 in. (32 mm)
Style Washers
Yes
Overview
- For 3/8" and 3/4" (10 and 19 mm) glass doors
- Includes mounting hardware (through-bolts, washers, gaskets)
- Available in several sizes and finishes
- For use with monolithic tempered glass
CRL Glass Mounted Mitered Corner Style Pull Handles — SKU: MH18X18PS are constructed from 1" (25 mm) round stainless steel tubing. The mitered corners deliver a clean, modern look for all‑glass door applications and long‑lasting commercial performance.
SPECIFICATIONS:
For Use With: 3/8" to 3/4" (10 to 19 mm) glass (monolithic tempered recommended)
Construction: 1" (25 mm) round stainless steel tubing
Glass Fabrication Required: Two 5/8" (16 mm) diameter holes
INCLUDES:
2 Each: Through‑bolts for glass mounting
4 Each: 1-1/4" (32 mm) diameter matching‑finish metal washers and rubber gaskets
Stainless Steel Advisory:
Stainless steel resists corrosion but is not rust‑proof. Periodic maintenance helps preserve the factory finish. See the Stainless Steel Disclaimer in Technical References for care instructions.
Ideal for commercial and residential glass door projects requiring a modern mitered corner pull handle and complete through‑bolt mounting hardware. Order SKU MH18X18PS or contact us for custom sizes and finish availability.
Specifications
CAD Drawings - dwg
