CRL 316 Stainless Steel 84" Upward-Locking Ladder Door Pull

• Locks Into the Ceiling Only — no floor strike required
• A.D.A. Compatible Thumbturn mounted at a comfortable 42" (1.07 m) above finished floor
• Adaptor Kits Available for 1-3/4" (45 mm) Thick Doors - LLPA134ADT
• Lock Operates at a Comfortable 42" (1.07 m) Above the Floor
• 1-1/4" (32 mm) Diameter Alloy Tubing available in 316 Brushed or Polished Stainless Steel
• Custom Sizes Ship within One to Two Weeks
• A.D.A. Compliant Models Available — Ask for a Quote Here

Our CRL LLPUA Series Upward Locking Ladder Pulls (SKU: LLPUA84BS) are engineered for tempered glass doors 1/2" to 3/4" (12–19 mm) thick. The fully concealed deadbolt locks upward into the ceiling (not the floor), providing a clean look and eliminating floor strikes. Ideal long-tail use cases: upward locking ladder pull for glass doors, upward locking pull with ADA thumbturn, and 316 stainless steel ladder pull for commercial glass entrances. Available finishes: brushed stainless steel and polished stainless steel.

This upward locking ladder pull ships with a standard 7-pin Rim Cylinder with Interchangeable Core (IC) — use it as supplied, remove the core for rekeying, or replace the core. A selection of 7-pin cores is available. The pull also accepts most standard rim-type cylinders if you prefer proprietary 6-pin or alternate cylinders.

NOTE: Glass fabrication is required. Push/pull indicators and Dustproof Keepers are sold separately.

Stainless Steel Advisory:

Features at a glance: concealed upward deadbolt · ADA-compatible thumbturn · interchangeable 7-pin IC cylinder · 316 stainless options · custom sizes available. Order the LLPU
