CRL Brite Chrome Vernon Oil Dynamic 180° Glass Hinge No Hold-Open

• For self-closing glass doors 5/16" to 9/16" (8 to 13.52 mm) thick
• Aluminum body available in three finishes: Brite Chrome, Brushed Satin, Satin Anodized
• Hold-open or no hold-open models
• Adjustable closing speed via control valve
• Excellent alternative to floor closers and patch fittings for retrofit all-glass installations

CRL 180 Degree Glass-to-Glass Hinge (SKU: H8215CH) — an Oil Dynamic self-closing glass door hinge designed for interior doors (not for shower doors). Swings 90° in and out with a positive stop at 0°. Adjustable hydraulic closing speed lets you tune the door action without floor- or overhead-mounted hardware, ideal for installing an all-glass door in existing openings.

Use two hinges for doors up to 39" (1 m) wide and a maximum combined weight of 176 lbs. (80 kg). Ambidextrous design supports left- or right-hand installations. Precision-tested for durability (over 1 million cycles) to ensure long-lasting performance.

Highlights / Differentiators:

• Oil Dynamic hydraulic action for smooth, reliable self-closing of glass doors
• Retrofit-friendly: eliminates need for floor closers or overhead closers when paired with two hinges
• Ambidextrous design and adjustable closing speed for flexible interior door layouts
• Durability proven by 1,000,000+ cycle testing

Specifications:
Glass Thickness Range: 5/16" to 9/16" (8 to 13.52 mm)
Construction: Aluminum
Hinge Swings: 90° inward and outward (except specific one-way models)
Closing Type: Automatic closing from 0° to 80°
Includes: Snap-in molded gaskets for 5/16"–9/16" glass; hex screws
Maximum Capacities (using two hinges): Door width: 39" (1 m); Max door weight: 176 lbs. (80 kg)

Installation Notes & Product Warning:

• Do not use more than two hinges on one door.
• Designed for interior door applications—NOT for shower door use.
• Use only the included hinge template; cut-out dimensions may differ from other brands.
• If using for unintended applications, obtain approval from CRL Technical Sales.
