CRL Dark Bronze Top Patch Fitting for Glass Door with 1NT303 Insert
CRL Dark Bronze Top Patch Fitting for Glass Door with 1NT303 Insert
Regular price
$67.09 CAD
Regular price
Sale price
$67.09 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# PH20ADU
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Black Bronze Anodized
Glazing Thickness
3/8 in., 1/2 in. (10 mm, 12 mm)
Height
2 in. (51 mm)
Insert Type
1NT303
Length
6-7/16 in. (164 mm)
Maximum Door Height
102 in. (2591 mm)
Maximum Panel Weight
194 lbs. (88 kg)
Maximum Width
42 in. (1067 mm)
Pivot Setback
2-3/4
Type
Top
With Insert
Yes
Overview
- For 3/8" or 1/2" (10 or 12 mm) glass
- With or without locks
- 2-3/4" (70 mm) pivot setback
- Use monolithic tempered glass
CRL Top Gate Patch Fittings (SKU: PH20ADU) are a brushed stainless steel top corner patch designed for glass gates and frameless glass doors. Engineered to work with all three CRL gate and door pivots, this top gate patch fitting installs in the upper corner of the glass panel and requires a hole and corner cut-out. Includes a glass cut-out template and step-by-step instructions for accurate glass fabrication.
Use these specifications when planning a gate or frameless glass door with this patch fitting:
Maximum Height: 102" (2.59 m)
Maximum Weight: 194 lbs. (88 kg)
Maximum Width: 42" (1.07 m)
If your door exceeds any of these limits, specify full door rails or alternate hardware.
Glass fabrication required:
One 3/4" (19 mm) diameter hole and a corner notch in monolithic tempered glass.
Comes with:
Template and instructions.
Do not use with:
PH42L, PH42R, PH43L or PH43R transom patch fittings. These require European door patch fitting PH21A.
Product warning:
Not for use with laminated glass.
Call or order online to get the PH20ADU top gate patch fitting and the glass template you need.
Specifications
CAD Drawings - dwg
