Product Details
- Mounts to Ceiling Instead of Traditional Side Mounting Application
- Three Stopping Points Include 45 Degrees Out, Closed Position, and 45 Degrees In
- Stocked in Five Popular Finishes
- Use Monolithic Tempered Glass
- Glass Thickness: 5/16" to 1/2" (8 to 12 mm)
- Material: Solid Brass
- Includes: Gaskets, Mounting Screws, Phillips Screws, Allen Screws, and Glass Fabrication Dimensions
- Gaskets are included for 3/8" and 1/2" (10 and 12 mm) glass only. If using 5/16" (8 mm) glass, Cat. No. GEN13 Gaskets must be ordered. Cut-Out Required NOTE: Maximum transom size is 28" W x 12" H (711 x 305 mm). Two Clamps must be used per transom. It is recommended to come in 6" (152 mm) to the center of the cutout for each Clamp.
Our CRL 3-Point Movable Transom Clamps provide design alternatives to the traditional side mounted "teeter-totter" application. Mounted to the ceiling instead of the sides of the transom allows more glass exposure. The Clamps will hold at 45 degrees inward, at the closed position, and at 45 degrees outward. The square or beveled appearance matches many of our popular Hinge Series. Accommodates 1/2", 3/8", and 5/16" (12, 10, and 8 mm) thick tempered glass.
SPECIFICATIONS:
Glass Thickness: 5/16" to 1/2" (8 to 12 mm)
Material: Solid Brass
Includes: Gaskets, Mounting Screws, Phillips Screws,
Allen Screws, and Glass Fabrication Dimensions
Gaskets are included for 3/8" and 1/2" (10 and 12 mm) glass only. If using 5/16" (8 mm) glass, Cat. No. GEN13 Gaskets must be ordered.
Cut-Out Required
NOTE: Maximum transom size is 28" W x 12" H (711 x 305 mm). Two Clamps must be used per transom. It is recommended to come in 6" (152 mm) to the center of the cutout for each Clamp.
