CRL Polished Brass Pivot Hinge for Frameless Glass Doors
CRL Polished Brass Pivot Hinge for Frameless Glass Doors
Regular price
$37.30 CAD
Regular price
Sale price
$37.30 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# EH226
Shipping Weight: 4.96 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pack
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 4.96 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pack
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Polished Brass
Glazing Thickness
1/4 in. To 5/16 in. (6mm To 8 mm)
Height
1-1/16 in. (27 mm)
Material
Brass
Maximum Door Width
14 in. (355.6 mm)
Pack Quantity
2
Weight Capacity
18 lbs. (8.2 kg)
Width
1-9/16 in. (39.7 mm)
Overview
- No holes or cut-outs required — installs without drilling
- Available in several finishes
- Fits 1/4" to 5/16" (6 to 8 mm) glass
- Easy-to-install, one set (top and bottom) per pack
Maximum recommended door width: 14" (356 mm) for Standard Hinges; 20" (508 mm) for Wide Hinges. Maximum weight: 18 lbs. (8.2 kg) for Standard Series; 28 lbs. (12.7 kg) for Wide Series. Minimum required clearance: 3/16" (5 mm) top and bottom.
Product Warning: If the glass door exceeds 14" (356 mm) wide or 20 lbs. (9 kg) total weight, use Cat. No. EH324 Hinge (heavier duty).
Brass Finish Advisory:
Although durable, brass is prone to oxidation and may develop a tarnished appearance over time regardless of packaging or storage. See the Brass Finish Disclaimer in the Technical References for care and maintenance.
SKU: EH226 — Ideal for frameless glass cabinet and display doors requiring a no-drill glass hinge solution.
Contact CRL Customer Service or add SKU EH226 to your cart to order today.
