CRL AMR Series Brushed Stainless Double-Keyed Lock Cylinders

• High Density Cast Body with Lock Mechanism
• Gaskets for use with 3/8" or 1/2" (10 or 12 mm) Glass
• Five Architectural Finishes

The CRL American Style Patch Lock (SKU: AMR205CCBS) is a versatile patch lock for glass doors and panels—designed for top, bottom or side mounting. It installs on the door face or vertical edge and secures to a jamb using the supplied Keeper. For sidelites or glass-to-glass applications use the AMR206 Sidelite Mount Keeper. Optional keepers such as AMR207 and AMR208 accommodate most installation types, making this a flexible glass door hardware solution.

Optional cylinders (ordered separately) include AMR205CC double-keyed cylinders and AMR205CT single-key cylinder with thumbturn.

GLASS FABRICATION REQUIRED:
Top or Bottom Mount:
One 3/4" (19 mm) diameter hole and one corner notch
Side Mount:
One 3/4" (19 mm) diameter hole and one U-cutout (hole on top)

COMES WITH:
Template and Instructions

DOES NOT INCLUDE:
Double keyed cylinders; keyed cylinder/thumbturn; optional keepers (must be ordered separately)

DOUBLE DOOR APPLICATION:
For double door installations a bottom patch lock is required on the inactive leaf to properly secure the pair of doors.

Stainless Steel Advisory:

Reliable, architect-grade patch lock for glass doors in multiple finishes — order the AMR205CCBS today to complete your glass door hardware project.
