CRL Brushed Bronze 180° Glass-to-Glass Clamp, Traditional Style

CRL Brushed Bronze 180° Glass-to-Glass Clamp, Traditional Style

Regular price $63.91 CAD
Regular price Sale price $63.91 CAD
Sale Sold out
Shipping calculated at checkout.
Quantity
Item# GCB180BBRZ
Shipping Weight: 8.96 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
Brushed Bronze
Glass To Glass Angle
180
Glazing Thickness
5/16 in. To 1/2 in. (8 mm To 12 mm)
Material
Brass
Mounting Type
Glass To Glass
Series
Traditional

Overview

  • For 5/16" to 1/2" (8 or 12 mm) thick glass
  • Use monolithic tempered glass
  • Secures fixed panels in frameless shower enclosures
  • Solid brass construction
  • Cleaner, all-glass appearance versus traditional U-channel
  • Glass fabrication required to accommodate clamps

Solid brass CRL Standard 180 Degree Glass Clamps (SKU: GCB180BBRZ) provide a durable, attractive solution for securing fixed transom or inline panels in frameless shower enclosures. Designed for monolithic tempered glass, these 180° clamps help achieve an "all-glass" look that’s cleaner than U-channel installations while matching CRL Shower Door Hinges finishes.

All Traditional Clamps feature solid brass construction and include appropriate mounting screws plus one set of clear gaskets. Extra clear gaskets (Cat. No. UCG77) are available separately for 5/16" (8 mm) glass.

SPECIFICATIONS:
Materials: Solid Brass
Available Finishes: Shown at top of page
Glass Thickness Range: 5/16" to 1/2" (8 to 12 mm)
Fabrication Required: Stud will fit between panels with a 7/16" (11 mm) gap, or glass can be notched around the screw stud for a tighter gap
Includes: Gaskets (one set)
NOTE: An additional set of gaskets is required for 5/16" (8 mm) glass (Cat. No. UCG77).

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs for your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation; colors may vary depending on your monitor.


Choose the GCB180BBRZ solid brass 180° glass clamp for a durable, low-profile fastening solution in frameless shower installations — order now to complete your all-glass design.
