CRL Brushed Nickel 180° Corner Glass Clamp for Frameless Panels

• For 5/16" to 1/2" (8 or 12 mm) thick glass
• Use monolithic tempered glass
• Secures fixed panels of glass for frameless shower enclosures
• Solid brass construction
• Provides an all-glass look as an alternative to U-channel
• Glass fabrication required to accommodate clamps

Solid brass CRL Standard 180 Degree Glass Clamps (SKU: GCB180BN) are engineered for fixed transom and inline panel installations in frameless shower enclosures. These traditional glass clamps secure glass panels while preserving a clean, contemporary frameless appearance—making them a preferred solid brass glass clamp for frameless shower projects.

Designed to complement our full line of shower door hinges, each clamp ships with appropriate mounting screws and one set of clear gaskets. Extra clear gaskets (Cat. No. UCG77) are available separately for 5/16" (8 mm) glass.

SPECIFICATIONS:
Materials: Solid brass
Available Finishes: Shown at top of page
Glass Thickness Range: 5/16" to 1/2" (8 to 12 mm)
Fabrication Required: Stud will fit between panels with 7/16" (11 mm) gap, or glass may be notched around the screw stud for a tighter gap
Includes: Gaskets
NOTE: An additional set of gaskets is required for 5/16" (8 mm) glass (Cat. No. UCG77).

Order the solid brass GCB180BN glass clamp today to maintain a seamless frameless shower look—contact us for availability and lead time.
