CRL Brushed Bronze Oversized U-Clamp for Fixed Shower Glass

• Recommended for 1/2" (12 mm) glass
• Use monolithic tempered glass
• Secures fixed panels of glass for frameless shower enclosures
• Solid brass construction
• Offers an all-glass look compared to traditional U-channel
• Glass fabrication required to accommodate clamps

CRL Oversized Fixed Panel U-Clamps (SKU: UC79BBRZ) are heavy-duty, solid brass clamps engineered for frameless shower glass panels, especially recommended for 1/2" (12 mm) tempered glass where temperer-required hole placement equals 1.5× glass thickness. These oversized fixed panel U-clamps provide a cleaner, more contemporary alternative to U-channel while maintaining secure, durable support for fixed glass panels.

Our traditional solid brass glass clamps are available in multiple finishes to match CRL shower door hinges. Each clamp includes appropriate mounting screws and one set of clear gaskets. Extra clear gaskets (Cat. No. UCG77) are available separately.

SPECIFICATIONS:
Material: Solid Brass
Glass Thickness Range: 5/16" to 1/2" (8 to 12 mm)
Hole Diameter Required: 5/8" or 3/4" (16 or 19 mm)
Includes: Mounting screw and clear gaskets

NOTE: An additional set of clear gaskets (Cat. No. UCG77) is required for 5/16" (8 mm) glass.

Looking for frameless shower glass clamps for 1/2-inch glass? Order SKU UC79BBRZ or contact CRL for pricing and finish options.
