CRL Z-Series Brushed Nickel Round 2" Radius Glass Clamp for 3/8"

• For 3/8" (10 mm) glass
• Zinc casting (also available in stainless steel)
• Designed for mezzanines, partitions, railings and windbreaks
• Use with monolithic tempered glass
• Steel pin available for additional glass support (included)
• Tested and engineered to meet and exceed code standards
• Custom painted finishes available upon request

Our CRL Z-Series Round Type Radius Base Glass Clamps (SKU: Z210BN) are precision fittings for glass thicknesses from 1/4" to 1/2" (6–12 mm). Available in zinc casting or stainless steel, these radius-base glass clamps are ideal for exterior and interior applications including partitions, railings, windbreaks and other architectural glass projects. Use with 1-1/2" or 2" (38 or 50.8 mm) diameter round tubing.

For securing the Z-clamp to thin wall tubing (less than 1/8"), use CRL’s ZB0LT Socket Head Cap Bolt and ZRNUT Rivet-Nut. Drill a 17/32” (13.5 mm) hole, then install the Rivet-Nut using the 34604 Heavy-Duty Thread Insert tool with 34618 5/16” mandrel and nosepiece.

NOTE: A 1/2" (12 mm) notch is required if using the steel pin (included) for additional glass support.

SPECIFICATIONS:

Glass Thickness: For 3/8" (10 mm) (fits 1/4"–1/2" (6–12 mm) glass)

Base Design: Radius

For Use With: 1-1/2" or 2" (38 or 50.8 mm) diameter round tubing

Material: Zinc casting or stainless steel. Stainless steel or powder-painted zinc recommended for exterior durability.

Glass Fabrication:

• For 1/4" (6 mm), 5/16" (8 mm), 3/8" (10 mm): 1/2" (12 mm) notch required if using provided steel pin for glass support
• For 1/2" (12 mm): 9/16" (14 mm) diameter hole required if using provided steel pin for glass support

Includes: Rubber gaskets and steel pin with grommet

Replacement Hardware: CRL ZCS5X5SS replacement screws; replacement gaskets: CRL Cat. No. Z38RG
