CRL Oil Rubbed Bronze Geneva 544 Series Wall Mount Offset Back Plate Hinge

CRL Oil Rubbed Bronze Geneva 544 Series Wall Mount Offset Back Plate Hinge

$98.90 CAD
$98.90 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# GEN5440RB
Shipping Weight: 1.52 Pounds
Shipping Limitations: None
This Product Ships Free!
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
View full details

Product Information

Description

5 Degree Pre-Set YesNo
BackPlate Offset
EdgeProfile Square
Finish/ColorOil Rubbed Bronze
Glazing Thickness5/16 in. To 1/2 in. (8 mm To 12 mm)
Height 3-1/2 in.(89 mm)
MaterialBrass
Maximum Door Weight - 2 Hinges 80 lbs.(36.3 kg)
Maximum Door Weight - 3 Hinges 120 lbs.(54.4 kg)
Maximum Door Width -2 Hinges 28
Maximum Door Width -3 Hinges 32
MountingType Wall Mount
Self-Centering YesGeneva
Width 2-3/16 in.(56 mm)

Overview

The CRL Geneva Series offers professional-grade shower door hinges designed to accommodate 5/16" to 1/2" tempered safety glass, providing flexibility with six different styles, including wall mount and glass-to-glass types.
These self-centering hinges come with a reversible 5-degree pivot pin, allowing for customizable closure angles, and are built from solid brass with stainless steel moving parts for reliable performance.
Available in various beautiful finishes, the Geneva Hinges include a three-year warranty, ensuring long-lasting quality for both residential and hotel applications.
For custom installations, contact CRL's Technical Sales Shower Door Department to explore options like Custom Pivot Pins to meet specific design needs.
