CRL BM Satin Brass 8" Pull Handle & 18" Towel Bar for Glass Doors

CRL BM Series Pull Handle + Towel Bar Combination — SKU BM8X18SB

• Available in several durable decorative finishes
• Designed for shower enclosures — includes exterior towel bar
• Attractive 1-1/4" (32 mm) metal washers with protective plastic washers
• Uses monolithic tempered glass compatible hardware

Overview: The CRL BM Series Pull Handle/Towel Bar Combination with Metal Washers includes all installation hardware. Constructed from 3/4" (19 mm) diameter brass tubing (1.5 mil thick), each set pairs a pull handle with a towel bar and features decorative metal back-up washers plus plastic washers to protect glass-to-metal contact.

Key features for shower door hardware: heavy brass tubing construction, decorative metal washers, protective plastic washers, and suitability for monolithic tempered glass shower enclosures.

SPECIFICATIONS:

Material: 3/4" (19 mm) diameter brass tubing (1.5 mil thick)
Washer Diameter: 1-1/4" (32 mm)
Glass Thickness Range: 1/4" to 1/2" (6 to 12 mm)
Hole Diameter Required: 1/2" (12 mm)

Center-to-Center Hole Spacing:
6" Pull = 6" (152 mm)
8" Pull = 8" (203 mm)
12" Pull = 12" (305 mm)
12" Towel Bar = 12" (305 mm)
18" Towel Bar = 18" (457 mm)
20" Towel Bar = 20" (508 mm)
22" Towel Bar = 22" (559 mm)
24" Towel Bar = 24" (610 mm)

AVAILABLE SIZES / Catalog Numbers:
Cat. No. BM6X12 — 6" Pull / 12" Towel Bar
Cat. No. BM6X18 — 6" Pull / 18" Towel Bar
Cat. No. BM6X22 — 6" Pull / 22" Towel Bar
Cat. No. BM6X24 — 6" Pull / 24" Towel Bar
Cat. No. BM8X18 — 8" Pull / 18" Towel Bar (BM8X18SB)
Cat. No. BM8X20 — 8" Pull / 20" Towel Bar
Cat. No. BM8X22 — 8" Pull / 22" Towel Bar
Cat. No. BM8X24 — 8" Pull / 24" Towel Bar
