CRL Satin Brass Bottom Patch for Glass Door w/ 1NT301 Insert
CRL Satin Brass Bottom Patch for Glass Door w/ 1NT301 Insert
Regular price
$354.07 CAD
Regular price
Sale price
$354.07 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# PH10CSB
Shipping Weight: 1.275 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 1.275 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Satin Brass
Glazing Thickness
3/8 in., 1/2 in. (10 mm, 12 mm)
Insert Type
1NT301
Pivot Setback
2-3/4
Type
Bottom
With Insert
Yes
Overview
- 2-3/4" (70 mm) Pivot setback
- Fits 3/8" or 1/2" (10 or 12 mm) monolithic tempered glass
- Glass fabrication required (hole and corner notch)
CRL Bottom Gate Patch Fittings (SKU: PH10CSB) provide a low-profile corner connection for frameless glass gates and glass gate doors. Designed for use with CRL bottom door pivots and floor closers, this brushed stainless steel bottom gate patch fitting secures the lower corner of the glass panel and includes a glass cut-out template and installation instructions.
GLASS FABRICATION REQUIRED:
One 3/4" (19 mm) diameter hole and corner notch in the glass.
COMES WITH:
Template and instructions.
Product Warning:
Not for use with laminated glass.
Use the following guidelines when installing on 1/2" (12 mm) glass doors:
Maximum height: 102" (2.59 m)
Maximum weight: 176 lbs (80 kg)
Maximum width: 42" (1.09 m)
If the door exceeds any of these limits, use full door rails.
Brass Finish Advisory:
Brass and brass finishes can oxidize and develop a tarnished appearance over time despite packaging or storage. See the Brass Finish Disclaimer in Technical References for more details.
Key differentiators:
- Brushed stainless steel finish for corrosion resistance and modern appearance
- Includes glass cut-out template for accurate fabrication
- Specifically engineered for CRL bottom pivots and floor closers
Order PH10CSB bottom gate patch fittings now
Specifications
CAD Drawings - dwg
