CRL Satin Brass Square 180° Adjustable Glass-to-Glass Transom Clamp
CRL Satin Brass Square 180° Adjustable Glass-to-Glass Transom Clamp
Regular price
$40.08 CAD
Regular price
Sale price
$40.08 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# SGC188SB
Shipping Weight: 15.44 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 15.44 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Design Style
Squared
Enclosure Type
Niche, Tailor Made Solutions
Finish/Color
Satin Brass
Glass To Glass Angle
180
Glazing Thickness
3/8 in. To 1/2 in. (10 mm To 12 mm)
Height
2 in. (51 mm)
Material
Brass
Mounting Type
Pivoting Glass To Glass
Width
4-1/16 in. (103 mm)
Overview
- For 3/8" to 1/2" (10 to 12 mm) Thick Glass
- Glass Transom Swivels to Allow Release of Steam
- Wall Mount and 180 Degree Models Available
- Solid Brass Material
- Use Monolithic Tempered Glass
CRL Square 180 Degree Glass-to-Glass Movable Transom Clamps provide a durable brass glass transom clamp solution for shower and storefront applications, allowing a movable transom to rotate off an inline fixed glass panel for ventilation and steam release. For balanced operation the clamp must be centered on the transom. Maximum movable transom size: 16" x 30" (406 x 762 mm). SKU: SGC188SB.
NOTE: Replacement Parts: 90295A120 (Nylon Washer), 211039 (10-32 x 3/4" Flat Head Phillips Screw), 193004 (10-32 Nylon Lock Nut).
SPECIFICATIONS:
Materials: Solid Brass
Glass Thickness Range: 3/8" to 1/2" (10 to 12 mm)
Glass Fabrication Required: SGC180, SGC135, SGC90, and SGC186 require 3/4" (19 mm) holes; SGC188 requires a 3/4" (19 mm) hole in the fixed panel and a notch in the transom
Includes: Mounting screws (for wall clamps) and gaskets
Brass Finish Advisory:
Brass is durable but can oxidize over time, which may cause a tarnished appearance regardless of initial packaging. See the Brass Finish Disclaimer in Technical References for care and maintenance tips.
Order the SGC188SB brass glass transom clamp for reliable 180-degree movement and steam-release functionality — add to cart or contact us for fabrication guidance.
