CRL Satin Brass Square Wall-Mount Adjustable Transom Clamp for Glass
CRL Satin Brass Square Wall-Mount Adjustable Transom Clamp for Glass
Regular price
$24.92 CAD
Regular price
Sale price
$24.92 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# SGC186SB
Shipping Weight: 8.16 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 8.16 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Design Style
Squared
Enclosure Type
Niche, Tailor Made Solutions
Finish/Color
Satin Brass
Glazing Thickness
3/8 in. To 1/2 in. (10 mm To 12 mm)
Height
2 in. (51 mm)
Material
Brass
Mounting Type
Wall Mount
Width
2 in. (51 mm)
Overview
- For 3/8" to 1/2" (10 to 12 mm) thick glass
- Glass transom swivels to allow release of steam
- Wall-mount and 180° models available
- Solid brass material
- Use with monolithic tempered glass
CRL Square Wall Mount Movable Transom Clamps — SKU SGC186SB are precision brass clamps designed to rotate a movable transom away from a wall for ventilation or steam release. Clamp must be centered on the transom for balanced movement. Maximum movable transom size: 16" x 30" (406 x 762 mm). Replacement parts: Nylon washer Cat. No. 90295A120; gasket Cat. No. SGCU1G.
SPECIFICATIONS:
Materials: Solid brass — durable finish for hardware and decorative applications
Glass thickness range: 3/8" to 1/2" (10 to 12 mm) — for monolithic tempered glass panels
Glass fabrication required: SGC180, SGC135, SGC90, and SGC186 require 3/4" (19 mm) holes
Includes: Gaskets and mounting screws
NOTE: Maximum transom size is 16" x 30" (406 x 762 mm). Larger transoms require pivot hinges used as transom clamps — contact CRL for details.
Brass Finish Advisory:
Brass is durable but prone to oxidation, which can cause a tarnished appearance over time regardless of packaging or storage. See the Brass Finish Disclaimer in Technical References for care and maintenance details.
Order the SGC186SB wall-mount movable transom clamp for secure, steam-release ventilation — contact CRL or add to cart today.
