CRL 10 in Satin Anodized Aluminum Back-to-Back Glass Door Pull

CRL 10 in Satin Anodized Aluminum Back-to-Back Glass Door Pull

$138.87 CAD
$138.87 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# CM10X10SA
Shipping Weight: 2.2 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Diameter
1 in. (25 mm)
Finish/Color
Satin Anodized
Glazing Thickness
3/8 in. To 3/4 in. (10 mm To 19 mm)
Mounting Center To Center
10 in. (254 mm)
Mounting Hole Diameter
5/8 in. (16 mm)
Mounting Type
Back-to-Back
Style Washer Diameter
1-1/4 in. (32 mm)
Style Washers
Yes

Overview

  • Stocked in up to five architectural finishes
  • For use with 3/8" to 3/4" (10 to 19 mm) glass
  • Complete with matching finish metal washers and through-bolts for mounting
  • Use monolithic tempered glass

This CRL Glass Mounted Standard Pull Handle (SKU: CM10X10SA) is a durable glass door pull designed for commercial and architectural glass doors. Available in multiple finishes and three sizes, it fits 10–19 mm tempered glass and ships with matching finish washers and through-bolts for straightforward installation.


SPECIFICATIONS:
For Use With: 3/8" to 3/4" (10 to 19 mm) glass (monolithic tempered glass recommended)
Construction:
1" (25 mm) diameter stainless steel or brass tubing. *1-1/4" (32 mm) diameter stainless steel (Cat. No. CD24X24BS125 model only).
Projection: 3" (76 mm) from face of glass to outside of handle
Glass Fabrication Required: Two 5/8" (16 mm) diameter holes

INCLUDES:
2x through-bolts for glass mounting
4x 1-1/4" (32 mm) diameter matching finish metal washers and rubber gaskets

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs, please request this prior to submitting your order by contacting CRL Customer Service. Product images are actual or close representations; colors may vary by monitor settings.
