CRL Trento 135° Polished Chrome Glass-to-Glass Shower Door Hinge

• Supports heavier glass shower doors (up to 175 lbs with three hinges)
• Concealed screws for a clean, modern look
• 135 Degree glass-to-glass pivot for frameless installations
• Single NAF gasket compatible with both 3/8” (10 mm) and 1/2” (12 mm) monolithic tempered glass
• Designed for monolithic tempered glass panels

CRL Trento Hinge (SKU: TNT045CH) is a heavy-duty, rectangular frameless shower door hinge engineered for modern bathrooms. Its narrow gap and fully concealed mounting screws provide a refined appearance while supporting large glass panels in residential and hotel shower installations.

The Trento uses compressible NAF gaskets to maintain a consistent grip on both 3/8" and 1/2" monolithic tempered glass across varying surface conditions. This makes it an ideal choice as a heavy-duty glass shower hinge and a reliable component for frameless shower door systems.

Standard reversible pivot pin: Each hinge includes a reversible pivot pin allowing a 5° self-centering adjustment (set to either 95° or 85°). Rotate the pin (do not flip) to fine-tune door closure and alignment for a tighter seal and smoother operation.

Load capacity:

• Using two hinges with 3/8" or 1/2" glass: supports doors up to 140 lbs (63 kg) and up to 40" (1016 mm) wide
• Using three hinges with 3/8" or 1/2" glass: supports doors up to 175 lbs (79 kg) and up to 40" (1016 mm) wide

Product Warning:

CRL Shower Door Hinges are intended for residential or hotel shower use only. For other applications, obtain approval from the CRL Shower Door Technical Sales Department. Use only the template provided with this hinge—cut-out dimensions may differ from other brands.

For specification questions or to order TNT045CH, contact CRL Customer Service or place your order online today.
