CRL Trento Offset Back Plate Hinge Polished Chrome - Glass Door

• Supports heavier glass shower doors — up to 140 lb (two-hinge) or 175 lb (three-hinge)
• Concealed screws for a clean, modern look
• Wall mount offset back plate — standard model
• Single NAF gasket compatible with both 3/8” and 1/2” (10 and 12 mm) glass
• Designed for monolithic tempered glass

The CRL Trento Hinge (SKU: TNT044CH) is a heavy-duty frameless shower door hinge engineered for modern residential and hotel showers. Its sleek rectangular body and narrow gap conceal mounting screws for a refined appearance while supporting larger glass panels in frameless shower installations.

The Trento hinge uses compressible NAF gaskets that fit 3/8" and 1/2" (10 and 12 mm) monolithic tempered glass, maintaining a consistent grip across varying glass surfaces to reduce flex and improve sealing.

Standard reversible pivot pin: Each hinge includes a reversible pivot pin that lets you fine-tune the door’s closed position. Rotate (do not flip) the pin to shift the self-centering angle by 5°—choose 95° or 85°—to ensure proper alignment, a tight seal, and smooth operation.

Load and size limits:

• Two-hinge installation: supports doors up to 140 lb (63 kg), maximum width 40" (1016 mm)
• Three-hinge installation: supports doors up to 175 lb (79 kg), maximum width 40" (1016 mm)

Product warning: CRL shower door hinges are intended for residential or hotel shower use only. For alternate applications, obtain approval from the CRL Shower Door Technical Sales Department. Use only the template included with this hinge; cut-out dimensions may differ from other brands.

Order the CRL Trento heavy-duty frameless shower door hinge (TNT044CH) for durable, concealed-screw mounting and reliable performance—add to cart or contact us for technical details.
