CRL Oil Rubbed Bronze Geneva 045 Series 135 Degree Glass-to-Glass Hinge

CRL Oil Rubbed Bronze Geneva 045 Series 135 Degree Glass-to-Glass Hinge

$189.11 CAD
$189.11 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# GEN0450RB
Shipping Weight: 2.5 Pounds
Shipping Limitations: None
This Product Ships Free!
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
View full details

Product Information

Description

5 Degree Pre-Set NoNo
EdgeProfile Square
Finish/ColorOil Rubbed Bronze
Glass To Glass Angle135
Glazing Thickness5/16 in. To 1/2 in. (8 mm To 12 mm)
Height 3-1/2 in.(89 mm)
MaterialBrass
Maximum Door Weight - 2 Hinges 80 lbs.(36.3 kg)
Maximum Door Weight - 3 Hinges 120 lbs.(54.4 kg)
Maximum Door Width -2 Hinges 28
Maximum Door Width -3 Hinges 32
MountingType Glass To Glass
Self-Centering YesGeneva
Width - Door Portion 2-3/16 in.(56 mm)
Width - Sidelite Portion2-9/16

Overview

The CRL Geneva Series Hinges are expertly designed for 5/16" (8 mm) to 1/2" (12 mm) glass, offering a versatile range with six distinct styles for both Wall Mount and Glass-to-Glass applications.
These self-centering hinges feature a reversible 5-degree pivot pin and are available in several stunning finishes, backed by a three-year warranty.
Constructed from solid brass with stainless steel moving parts, Geneva Hinges ensure durability and functionality.
For custom installations, CRL provides Custom Pivot Pins, allowing for precise angle adjustments to meet unique enclosure needs.
Ideal for residential or hotel showers, these hinges require specific cut-out dimensions, and custom finishes can be requested through CRL's Technical Sales Shower Door Division.
