CRL Geneva 180 Oil-Rubbed Bronze Glass-to-Glass 180° Shower Hinge

• Self-Centering with Reversible 5 Degree Pivot Pin
• Available in Several Beautiful Finishes
• Three Year Warranty
• 180 Degree Glass-to-Glass Standard Model (Factory Set for Standard Closing Position)
• Use Monolithic Tempered Glass

The CRL Geneva Series professional hinges (SKU: GEN1800RB) are precision glass shower door hinges designed for frameless and semi-frameless glass shower enclosures. Engineered to accept 5/16" (8 mm) to 1/2" (12 mm) tempered safety glass, Geneva Hinges offer six styles—three Wall Mount and three Glass-to-Glass—for maximum design flexibility in residential and hotel shower installations. Built from solid brass with stainless steel pins and springs, these solid brass shower hinges resist corrosion and provide long-lasting performance for glass shower doors.


Standard Reversible Pivot Pin: Each Geneva hinge includes a reversible pivot pin marked 90° on one side and 85° on the other. Standard models ship with the 90° side active; offset models ship pre-set to 85° for a 5° tighter closure into the shower interior. The pin can be rotated to change the closing angle.

Custom Pivot Pin: Custom Pivot Pins (Cat. No. GENP1N) are available up to 45° for off-angle installations—specify the angle when ordering. Using a custom pivot may affect glass sizes and enclosure aesthetics; contact our Technical Sales Shower Door Department for guidance.

With two hinges and 5/16"–1/2" (8–12 mm) glass, each hinge set supports up to 80 lbs. (36 kg) with a maximum door width of 28" (711 mm). Using three hinges, the set supports up to 120 lbs. (54 kg) with a maximum door width of 32" (813 mm).

SPECIFICATIONS:
Glass Thickness: 5/16" (8 mm) to 1/2" (12 mm) Tempered Safety Glass
Special Feature: Choice of Standard model (0° factory closing) or 5° Pre-Set model for tighter closure into the shower interior
Construction: Solid Brass with stainless steel pins and springs
Hinge Swings: 90° in and 90° out
Closing Type: Self-centering when within 15° of closed position
Cut-Out Required Includes: Gaskets, screws, and glass fabrication dimensions. Cat. No. GEN13 Gasket Pack must be purchased separately for use with 5/16" (8 mm) glass.

Custom finishes are available on request—contact the Technical Sales Shower Door Division for lead times and options.
