CRL Geneva 037 Gunmetal Wall-Mount Glass Door Hinge w/ Full Back Plate

• Self-centering hinge with reversible 5° pivot pin
• For monolithic tempered safety glass (5/16"–1/2" / 8–12 mm)
• Available in several beautiful finishes; custom finishes on request
• Wall-mount full back plate standard (factory set for standard closing position)
• Three year warranty

The CRL Geneva Series professional shower hinges (SKU: GEN037GM) fit 5/16" (8 mm) to 1/2" (12 mm) tempered safety glass and are available in six styles—three Wall Mount and three Glass-to-Glass—for flexible glass shower hinge design options. Geneva Hinges are self-centering and include a reversible 5° pivot pin; custom pivot pins are available for off-angle installations. All moving parts (pins and springs) are stainless steel; hinge bodies are made of solid brass for corrosion resistance and long life.

Standard Reversible Pivot Pin: Each hinge contains a reversible pivot pin marked 90° on one side and 85° on the other. Standard models ship with the 90° side active; offset models are pre-set to 85° (5° tighter closure into the shower interior). The pin can be rotated to change the active side.

Custom Pivot Pin: Custom Pivot Pins (Cat. No. GENP1N) can be specified up to 45° to accommodate unusual angles. Using a custom pin may affect glass sizes and enclosure aesthetics—contact Technical Sales Shower Door Department for assistance.

Using two hinges on 5/16"–1/2" glass, each hinge set will support up to 80 lbs. (36 kg) with a maximum door width of 28" (711 mm). Using three hinges supports up to 120 lbs. (54 kg) with a maximum door width of 32" (813 mm).

SPECIFICATIONS:
Glass Thickness: 5/16" (8 mm) to 1/2" (12 mm) Tempered Safety Glass
Special Feature: Choice of Standard model (0° closing) or 5° Pre-Set model for tighter closure into shower interior
Construction: Solid Brass with stainless steel pins and springs
Hinge Swings: 90° in and 90° out
Closing Type: Self-centering when within 15° of closed position
Cut-Out Required Includes: Gaskets, screws, and glass fabrication dimensions. Cat. No. GEN13 Gasket Pack required separately for use with 5/16" (8 mm) glass.

Custom finishes are available on
