CRL Vienna 180 Gunmetal Glass-to-Glass Shower Door Hinge

• Accommodates 3/8" to 1/2" (10 to 12 mm) tempered safety glass
• Available in several beautiful finishes (custom finishes available on request)
• 3 Year Warranty
• 180° glass-to-glass standard model (factory set for standard closing position)
• Designed for monolithic tempered glass

CRL Vienna Hinges (SKU: V1E180GM) provide heavy-duty, reliable support for wider and heavier shower doors when traditional hinges are insufficient. The hinge contains two internal steel pins that offer mounting flexibility: leave the pins in place for compatibility with CRL "mouse-ears" cut-outs for added safety, or remove them for increased adjustability and compatibility with CRL rectangular, square-corner cut-outs (and, in some cases, competitive rectangular cut-outs).

Standard Reversible Pivot Pin: Each Vienna Hinge includes a reversible pivot pin with a 90° side and an 85° side. Standard models ship with the 90° side activated; pre-set models are set to 85° for a 5° tighter closure into the shower interior. Rotate (do not flip) the pin to switch sides.

Custom Pivot Pin: Custom pivot pins are available for off-angle installations (specify angle needed, up to 45°). Useful when walls or site conditions prevent a 90° installation.

Load Capacity:

• Two hinges (3/8"–1/2" glass): supports up to 110 lb. (50 kg), max door width 36" (914 mm).
• Three hinges (3/8"–1/2" glass): supports up to 140 lb. (63 kg), max door width 36" (914 mm).

Specifications:
Glass Thickness: 3/8" (10 mm) to 1/2" (12 mm) tempered safety glass
Construction: Solid brass
Hinge Swings: 90° in and 90° out
Closing Type: Self-centering when within 15° of closed position
Cut-Out Required: (Except V1E092 which requires cut-out for door and two holes for fixed panel) — use only the template included with this hinge; CRL cut-outs may differ from other brands
Includes: Gaskets, screws, and glass fabrication dimensions
Maximum Clamping Screw Torque: 60 lbf·in (677.9 cN·m)

Custom finishes and technical assistance are available through the CRL Technical Sales Shower Door Department.

Product Warning:
CRL shower door hinges are designed for residential or hotel shower use. For other applications, obtain approval from the CRL Shower Door Technical Sales Department.
